SX Series winches exceed the most demanding standards of today’s modern vehicles, while delivering an affordable and stylish design which incorporates many class leading features not found in other high-performance winches. Produces 12,000 lbs. of raw pulling power, the new SX series has an IP68 rating for dustproof and waterproof operation while the sleek modern look is finished with a durable metallic graphite powder-coat that is built to last. Combined with innovative features such as a patented drum light, relocatable control box and a lighted remote, and steel wire rope this winch has it all.
12,000 lbs. capacity
6.0 HP sealed motor
Relocatable die-cast aluminum control box
12 ft. wired remote with integrated lithium ION rechargeable LED flashlight (2277R Wireless Remote Upgrade Kit available)
Ergonomic pull-and turn clutch handle
3-stage planetary gearing with 231:1 ratio
Patented drum light
5/8 in. x 85 ft. wire rope
Drum diameter measures 2.5 in.
Heavy duty clevis winch hook
Stainless steel roller fairlead
100% full load holding automatic mechanical brake
IP68-rated waterproof and dustproof
Durable metallic graphite powder coat finish
Clockable gearbox
Specifications
Brake System 100% Full-load holding automatic mechanical brake
Clutch Pull and turn clutch handle
Color Graphite
Control Box Relocatable Die-Cast Aluminum
Dimensions 22.04in L x 6.3in W x 9.67in H (559.8mm L x 160.02mm W x 245.62mm H)
Drum Durable fully welded steel drum
EN Compliant No
Fairlead Stainless Steel 4-Way Roller
Finish Powder Coated
Finish/Color Graphite
Gear Ratio 231:1
Gear System 3-stage planetary
Package Height 13 in.
IP Rating IP68 Waterproof and Dustproof
Package Length 12 in.
Line Speed 68 Amps Motor Draw/23.4 FPM (7.13 MPM)
Material Steel
Motor 6.0 HP, 12V DC
Mounting Bolt Pattern 10in x 4.5in (254mm x 114.3mm)
Rated Single Line Pull (Lbs) 12000
Remote Control 12 ft Hand-held wired remote only included (wired remote features flashlight with built-in lithium ION battery. Recharges while plugged into winch.)
Remote Type Wire
Rope Length 3/8 in x 85 ft (9.5mm x 26m)
Rope Material Steel Wire
Task Lighting Patented drum light
Warranty Limited Lifetime Mechanical/7 Year Limited Electrical
